MCU for Motor Control

VS PART NUMBER: VS4111SOC

Applications:

BLDC motor for various applications
Permanent Magnet Synchronous Motor for various applications

VS4111SOC deliver precise motor control for a variety of industrial and home applications. This Soc embedded with MCU supports a wide range of motor control techniques, from basic Brushless DC (BLDC) 6-step scalar control for fans and simple industrial setups to highly advanced sensorless Field Oriented Control (FOC) for more complex systems. With built-in support for sensored feedback for positioning applications.

Features::

ARM CORTEX MCU 100MHZ
2x 16b 10Msps SAR ADC with 8x1 MUX
Temperature Sensor ±0.5DegC
4x HS OPAMPs
7x General Purpose High Speed Comparator
2x 8x 32b PWM Timers with 5ns Resolution
2x Oversampling Digital Filters SINC/FIR
2x Digital comparator, 4x UART, 2x SPI/I2S, 4x I2C
2x 512KB FLASH, 128KB RAM

Device & EVB Ordering Information

Part Number	Description	Package	Status	Order
VS4111SOC	MCU with driver control	QFN32	Available 2025	Order Now

Part Number	VS1114FEQ
Description	High Precision Weighing Scale Asic
Package	QFN32
Status	Available
Order Now

Part Number	VS1114FEQ
Description	High Precision Weighing Scale Asic
Package	QFN32
Status	Available
Order Now

Part Number	VS1114FEQ
Description	High Precision Weighing Scale Asic
Package	QFN32
Status	Available
Order Now

Evaluation Board

Our weighing scale chip evaluation board is now available for testing and development, offering engineers and product designers a comprehensive platform to evaluate the precision and performance of our cutting-edge analog signal chain technology. This board is designed for seamless integration and is optimized for applications requiring high accuracy in weight measurement. Equipped with our advanced chip, it allows for real-world testing in various industrial and consumer environments. To order your evaluation board, please visit our website or contact our sales team for more information.
