Motor Driver IC

VS PART NUMBER: VS6111GD

Applications:

Driver for low power motors
Solar MPPT/Chargers/Inverters

The VS6111GD is a 4x dual 1.0 A gate driver tailored to drive a high-side P-channel MOSFET and a low-side N-channel MOSFET in motor control applications operating with voltages up to 60V.

Features::

4-phase motors up to 10A coil current
Voltage Range 13V to 60V DC (65Vabs MAX)
Drives High−Side PMOS and Low−Side NMOS
Internal Resistors Turn Driver Off If No Inputs
Electrostatic Discharge (ESD) Protected: 4kV
Integrated DCDC to Power on Board Devices at 5V/0.5W
To be used with Vervesemi VSCM01 Mosfet Chip

Device & EVB Ordering Information

Part Number	Description	Package	Status	Order
VS6111GD	4 Channel Motor Coil Driver with DCDC	SOIC24	In Production	Order Now

Part Number	Description	Package	Status	Order
VS6111GD-EVB	Evaluation Board	N/A	In Production	Order Now

Part Number	VS6111GD
Description	4 Channel Motor Coil Driver with DCDC
Package	SOIC24
Status	In Production
Order Now

Part Number	VS6111GD-EVB
Description	Evaluation Board
Package	N/A
Status	In Production
Order Now

Evaluation Board

Our VS6111GD chip evaluation board is now available for testing and development, offering engineers and product designers a comprehensive platform to evaluate. To order your evaluation board, please visit our website or contact our sales team for more information.
